DS-2CD2345G0P-IHK 4MP 180° Ultra Wide Angle Turret Network Camera
1/2.7" Progressive Scan CMOS
2688 × 1520 @ 25fps
1.68 mm ultra wide angle fixed lens
IR; up to 10m
120dB WDR
H.265, H.265+, H.264, H.264+
Built-in micro SD/SDHC/SDXC card slot, up to 256 GB
3-Axis adjustment
Indoor
|
DS-2CD2523GO-IWSHK 4MP IR Fixed Wi-Fi Mini Dome Network Camera
1/3" Progressive Scan CMOS
2688 × 1520@30fps
2.8/4/6 mm fixed lens
IR: up to 10 m
H.265, H.265+
120dB WDR
PoE
EXIR
Wi-Fi Connection
Built-in Micro SD/SDHC/SDXC slot, up to
|
DS-2CD2121G0-IWSHK 2MP IR Fixed Wi-Fi Dome Network Camera
1/2.8" Progressive Scan CMOS
1920 × 1080@30fps
2.8/4/6 mm fixed lens
Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON);
H.265+, H.265, H.264+, H.264
120 dB WDR
2 Behavior analyses
BLC/3D DNR/ROI
Wi-Fi Connection
Built-in micro SD/micro SDHC/micro SDXC card slot, up to 128 GB
|
DS-2CD2146G1-I(S) 4 MP IR Fixed Dome Network Camera
Max. 2688 × 1520 @ 30fps
2.8 mm/4 mm/6 mm fixed lens
H.265, H.264
120dB WDR
False alarm reduction by human and vehicle target classification based on deep learning
Powered by Darkfighter
12 VDC & PoE (802.3af, class 3)
IR range: Up to 30 m
Support on-board storage, up to 128 GB
IP67 (If the camera is installed outdoor, the bracket DS-1253ZJ-* should be used together with other pendant mounting bracket or wall mounting bracket to reduce IR reflective in the rainy day),IK10
BLC/3D DNR/ROI
Color: 0.007 Lux @ (F1.2, AGC ON), 0.012 Lux @ (F1.6, AGC ON)
|
DS-2XE6126FWD-HS 2 MP Explosion-Proof Network Dome Camera
1/2.8” Progressive Scan CMOS
1920 × 1080 resolution
Stainless steel 316L
120dB WDR
3D DNR
IP68
Support H.265+/H.265/H.264+/H.264
Support 128G on-board storage
|
DS-2CD5546G0-IZ(H)SY 4MP IR Vari-focal Dome Network Camera
1/1.8” Progressive Scan CMOS
2560 × 1440 @ 30fps, MJPEG up to 1920 × 1080 @ 30fps
2.8 to 12 mm motor-driven lens
Color: 0.002 Lux @ (F1.2, AGC ON)
H.265, H.265+, H.264, H.264+
140dB WDR
3D DNR
IR range up to 30 m
Five streams and up to five custom streams
6 behavior analyses, 3 exception detection, and face detection
Built-in microSD/SDHC/SDXC card slot, up to 256 GB
Alarm I/O
IP67, IK10
Anti-IR reflection
Anti-Corrosion: NEMA 4X
|
DS-2CD2346G1-I/SL 4 MP IR Fixed Turret Network Camera
Max. 2688 ×1520 @30fps
2.8 mm/4 mm/6 mm/8 mm fixed lens
H.265+, H.264+
120dB WDR
Powered by Darkfighter
False alarm reduction by human and vehicle target classification based on deep learning
12 VDC & PoE (802.3af, class 3)
Built-in micro SD/SDHC/SDXC slot, up to 128G
BLC/3D DNR/HLC/ROI
0.012 Lux @ (F1.6, AGC ON), 0 Lux with IR
Built-in speaker
Strobe Light & Audio Alarm
Indoor
|
DS-2CD2H23FWD-IZ) 2 MP IR VF Network Turret Camera
1/3 progressive scan CMOS
3D DNR
1920 × 1080@30fps
Up to 30 m IR range
2.8 mm to 12 mm motorized vari-focal lens
PoE (Power over Ethernet)
H.265+, H.265, H.264+, H.264
IP67
Built-in micro SD/ SDHC/ SDXC card slot
|
(DS-2CD1143G0-I) 4 MP IR Fixed Network Dome Camera
1/3" progressive scan CMOS
3D DNR (Digital Noise Reduction)
2560 × 1440@20fps
Up to 30 m IR range
2.8 mm/4 mm/6 mm fixed lens
PoE (Power over Ethernet)
H.265+, H.265, H.264+, H.264
IP67, IK10
Dual stream
Digital WDR (Wide Dynamic Range)
|
(DS-2CD2185FWD-IS) 8 MP IR Fixed Dome Network Camera
Up to 8 megapixel high resolution
Max. 3840 × 2160@20fps
2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional
H.265, H.265+, H.264+, H.264
120dB Wide Dynamic Range
3D Digital Noise Reduction
DC12V & PoE (802.3af)
IR range: 30m
Support on-board storage, up to 128 GB
IP67, IK10
|
(DS-2CD2385FWD-I) 8 MP IR Fixed Turret Network Camera
Up to 8 megapixel high resolution
Max. 3840 × 2160@20fps
2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional
H.265, H.265+, H.264+, H.264
120dB Wide Dynamic Range
3D Digital Noise Reduction
DC12V & PoE (802.3af)
IR range: up to 30m
Support on-board storage, up to 128 GB
IP67
|
(DS-2CE56D0T-IRMF) HD1080P 4in1 IR Turret Camera
2 Megapixel high-performance CMOS
Analog HD output, up to 1080P resolution
2.8 mm/3.6 mm/6 mm fixed lens
True Day/Night
Smart IR, up to 20m IR distance
IP66
witchable TVI/AHD/CVI/CVBS
|
(DS-2CD2T35FWD-I5I8) 3 MP IR Fixed Bullet Network Camera
Up to 3 megapixel high resolution
Max. 2048 × 1536@30fps
2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional
Powered by Darkfighter
H.265, H.265+, H.264+, H.264
120dB Wide Dynamic Range
3D Digital Noise Reduction
DC12V & PoE (802.3af)
IR range: 50m, 80m, optional
Support on-board storage, up to 128 GB
|
(DS-2CD2025FWD-I) 2 MP IR Fixed Bullet Network Camera
Up to 2 megapixel high resolution
Max. 1920 × 1080 @30fps
2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional
Powered by Darkfighter
H.265, H.265+, H.264+, H.264
120dB Wide Dynamic Range
3D Digital Noise Reduction
DC12V & PoE (802.3af)
IR range: up to 30 m
Support on-board storage, up to 128 GB
IP67
|
(DS-2CD2685FWD-IZS) 8 MP IR Vari-focal Bullet Network Camera
1/2.5" Progressive Scan CMOS
3840 × 2160 resolution
2.8 to 12 mm focal length
H.265, H.265+, H.264+, H.264
120dB Wide Dynamic Range
BLC/3D DNR/ROI
IP67, IK10
4 behavior analyses and face detection
|
(DS-2CD1023G0-I) 2 MP IR Fixed Network Bullet Camera
1/2.8" progressive scan CMOS
3D DNR (Digital Noise Reduction)
1920 × 1080@30fps
Up to 30 m IR range
2.8 mm/4 mm/6 mm fixed lens
PoE (Power over Ethernet)
H.265+, H.265, H.264+, H.264
IP67
Dual stream
Digital WDR (Wide Dynamic Range)
|
DS-2CD5A46G0-IZ/UH 4 MP Varifocal Bullet Network Camera
1/1.8” Progressive Scan CMOS
2560 × 1440 @ 30 fps
2.8 to 12 mm motorized lens
H.265, H.265+, H.264, H.264+
5 defined streams and up to 5 custom streams
120dB WDR
IP67
Built-in microSD/SDHC/SDXC card slot, up to 256 GB
|
(DS-2DE2A204IW-DE3) 2MP 4× Mini Network IR PTZ Camera
1/3" progressive scan CMOS
Up to 1920 × 1080@30fps resolution
Min. illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
2.8 to 12mm, 4× optical zoom, 16× digital zoom
120 dB WDR, 3D DNR, HLC, EIS, Regional Exposure, Regional Focus
12 VDC & PoE
Up to 20 m IR distance
Support H.265+/H.265 video compression
IP66, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
(DS-2DE4A215IW-DE) 2MP 15x Mini Network IR PTZ Camer
1/2.8" progressive scan CMOS
Up to 1920 × 1080 resolution
Ultra-low light: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
5 mm to 75 mm, 15× optical zoom, 16× digital zoom
120 dB WDR, 3D DNR, HLC, BLC
Up to 50 m IR distance
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
12 VDC & PoE+ (802.3at, class4)
Support H.265+/H.265 video compression
IP66, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
DS-2AE4225T-D 2 MP Turbo 4-Inch Speed Dome
1/2.8" progressive scan CMOS
1920 × 1080 resolution
25× optical zoom, 16× digital zoom
120 dB true WDR (Wide Dynamic Range)
3D intelligent positioning
Switchable TVI/AHD/CVI/CVBS video outputs
|
DS-2AE7225TI-A 2 MP IR Turbo 7-Inch Speed Dome
1/2.8" HD progressive scan CMOS
1920 × 1080 resolution
25× optical zoom, 16× digital zoom
120 dB true WDR (Wide Dynamic Range)
Up to 150 m IR distance
3D intelligent positioning
Switchable TVI/AHD/CVI/CVBS video outputs
|
DS-2AE5225TI-A 2 MP IR Turbo 5-Inch Speed Dome
1/2.8" HD progressive scan CMOS
1920 × 1080 resolution
25× optical zoom, 16× digital zoom
120 dB true WDR (Wide Dynamic Range)
Up to 150 m IR distance
3D intelligent positioning
Switchable TVI/AHD/CVI/CVBS video outputs
|
(DS-2DE5225IW-AE) 2MP 25X 5" Network IR PTZ Camera
1/2.8" progressive scan CMOS
Up to 1920 × 1080@30fps resolution
Min. illumination:Colour: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
4.8 mm to 120 mm, 25× optical zoom, 16× digital zoom
WDR, HLC, BLC, 3D DNR, Defog, EIS, Regional Exposure, Regional Focus
Up to 150 m IR distance
24 VAC & Hi-PoE
Support H.265+/H.265 video compression
Audio input/output
Alarm input/output
IP66, TVS 4,000V lightning protection, surge protection and voltage transient protection
|
4MP 36× Network Speed Dome
1/1.8" progressive scan CMOS
Up to 2560 × 1440 resolution
Min. illumination:
Color: 0.002 Lux @(F1.5, AGC ON)
B/W: 0.0002 Lux @(F1.5, AGC ON)
36× optical zoom, 16× digital zoom
120 dB WDR, 3D DNR, HLC, BLC, Defog, EIS
24 VAC &Hi-PoE
Support H.265+/H.265 video compression
Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
IK10, IP67
|
8MP 36× Network IR Speed Dome
2/3” HD CMOS sensor
Up to 4096 × 2160 resolution
36X Optical Zoom
Min. Illumination:
Color: 0.005 Lux @(F1.5, AGC ON)
B/W: 0.0005 Lux @(F1.5, AGC ON)
0 Lux with IR
Smart Tracking
Smart Detection
200m IR distance
Optional wiper(-W)
Hi-PoE / 24VAC power supply
Support H.265+/H.265 video compression
Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
Rapid focus
IP67, IK10
|
DarkfighterX 2MP 25× IR Network Speed Domeb
2* 1/2.8” progessive scan CMOS sensor
Up to 1920 × 1080 resolution
25X Optical Zoom
Min. Illumination:
Color: 0.001 Lux @(F1.5, AGC ON)
B/W: 0.0001 Lux @(F1.5, AGC ON)
0 Lux with IR
Smart Tracking
Smart Detection
200m IR distance
Optional wiper(-W)
Hi-PoE / 24VAC power supply
Support H.265+/H.265 video compression
Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
|
(DS-8632NI-I8) Embedded 4K 32ch NVR
32-ch network cameras can be connected with up to 320Mbps incoming bandwidth
Up to 12 Megapixels resolution recording
New logical and visualized GUI design
Dual-OS design
ANR technology
HDD hot swap with RAID0, RAID1, RAID5, RAID6 and RAID10 storage scheme configurable
Up to 8 SATA interfaces and 1 eSATA interface for HDD connection, 10TB capacity for each HDD
Smart search for efficient playback
Support H.265+/H.265/H.264+/H.264/MPEG4 video formats
|
(DS-8616NI-I8) Embedded 4K 16ch NVR
16-ch network cameras can be connected with up to 256Mbps incoming bandwidth
Up to 12 Megapixels resolution recording
New logical and visualized GUI design
Dual-OS design
ANR technology
HDD hot swap with RAID0, RAID1, RAID5, RAID6 and RAID10 storage scheme configurable
Up to 8 SATA interfaces and 1 eSATA interface for HDD connection, 10TB capacity for each HDD
Smart search for efficient playback
Support H.265+/H.265/H.264+/H.264/MPEG4 video formats
|
(DS-8608NI-I8) Embedded 4K 8ch NVR
8-ch network cameras can be connected with 128Mbps incoming bandwidth
Up to 12 Megapixels resolution recording
New logical and visualized GUI design
Dual-OS design
ANR technology
HDD hot swap with RAID0, RAID1, RAID5, RAID6 and RAID10 storage scheme configurable
Up to 8 SATA interfaces and 1 eSATA interface for HDD connection, 10TB capacity for each HDD
Smart search for efficient playback
Support H.265+/H.265/H.264+/H.264/MPEG4 video formats
|
(DS-76087616NI-K2) Embedded 4K NVR
Third-party network cameras supported
Up to 8 Megapixels resolution recording
Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160) resolution
4-ch network cameras can be connected with 40M/60M/80M incoming bandwidth
Support dual-os to ensure high reliability of system running
Support various VCA detection alarm and VCA search
Support H.265/H.264/MPEG4 video formats
|
(DS-7604NI-K1) Embedded 4K NVR
Third-party network cameras supported
Up to 8 Megapixels resolution recording
Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160) resolution
4-ch network cameras can be connected with 40M/60M/80M incoming bandwidth
Support dual-os to ensure high reliability of system running
Support various VCA detection alarm and VCA search
Support H.265/H.264/MPEG4 video formats
|
(DS-7604NI-K1) Embedded Plug & Play 4K NVR
Third-party network cameras supported
Up to 8 Megapixels resolution recording
Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160) resolution
4-ch network cameras can be connected with 40M/60M/80M incoming bandwidth
Support dual-os to ensure high reliability of system running
Plug & Play with up to 4 independent PoE network interfaces
Support various VCA detection alarm and VCA search
Support H.265/H.264/MPEG4 video formats
|
(DS-96128256NI-I16) New Super 4K NVR
Third-party network cameras supported
Up to 12 Megapixels resolution recording
Video outputs at up to 4K (4096*2160) resolution
Supports decoding up to 20 channels at 1080P resolution
Up to 128/256 IP cameras can be connected with 512M/768M incoming bandwidth
Up to 24 SATA interfaces
Supports H.264+,H.264,MPEG4,H.265,MJPEG video format
Support redundant power supply to improve the system stability
Support HDD hot swap with RAID0,1,5,6,10 storage scheme configurable
Support various VCA detection alarm and VCA search
|
XVR5216A
Features
Embedded processor
H.264+/H.264 dual-stream video compression
Support HDCVI/AHD/TVI/CVBS/IP video inputs
Max 6/12/24 channels IP camera inputs, each channel up 5MP
Max 24/48/96Mbps Incoming Bandwidth
Smart Search and Intelligent Video System
|
XVR5114/5116HE-S2/51132
Features
Embedded processor
H.264+/H.264 dual-stream video compression
Support HDCVI/AHD/TVI/CVBS/IP video inputs
Max 6/12/24 channels IP camera inputs, each channel up
Smart Search and Intelligent Video System
|
DH-XVR5208/5216/5232A
Features
Embedded processor
H.264+/H.264 dual-stream video compression
Support HDCVI/AHD/TVI/CVBS/IP video inputs
Max 6/12/24 channels IP camera inputs, each channel up 5MP
Max 24/48/96Mbps Incoming Bandwidth
Smart Search and Intelligent Video System
|
DHI-NVR4208-8P-4KS2/ DHI-NVR4216-16P-4KS2/ DHI-NVR4232-32P-4KS2
Features
H.265/H.264 codec decoding
Max 200Mbps Incoming Bandwidth
Up to 8MP Resolution for Preview and Playback
HDMI/VGA simultaneous video output
Support IPC UPnP, 8PoE ports
Support ANR technology to enhance the storage reliability when the network break down
|
IPC-HDW1220S
Features
1/2.9” 2Megapixel progressive CMOS
H.264+ & H.264 dual-stream encoding
25/30fps@2M(1920×1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8 mm fixed lens (3.6mm optional)
Max IR LEDs Length 30m
IP67, PoE
|
HAC-HDW1200EM
Features
Max 30fps@1080P
HD and SD output switchable
3.6mm fixed lens (6mm optional)
Max. IR length 50m, Smart IR
IP67, DC12V
|
SD22204T-GN
Features
4x optical zoom
H.264 & MJPEG dual-streams encoding
Max. 25/30fps@1080P(1920x1080) & 50/60fps@720P resolution
WDR, Day/Night(ICR), Ultra DNR, Auto iris, Auto focus
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Max 100°/s pan speed
Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
Support intelligent 3D positioning with DH-SD protocol
Micro SD memory, POE
|
IPC-HDBW1000E-W
Features
1/4” 1Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 25/30fps@720P(1280×720)
DWDR, Day/Night, 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (2.8mm,6mm optional)
Wi-Fi support
DC12V
|
IPC-HDBW2100R-Z/VF
Features
1/3” 1.3Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
25/30fps@1.3M(1280×960)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7~12mm varifocal lens
Max IR LEDs Length 30m
IP66, IK10, PoE
|
IPC-HDBW2201R-ZS/VFS
Features
1/2.7” 2Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 20m
IP67, PoE
|
IPC-HDBW4120F
Features
1/3” 1.3Megapixel progressive scan CMOS
H.264&MJPEG triple-stream encoding
25/30fps@1.3M(1280×960)
Smart Detection supported
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (2.8mm, 6mm optional)
Max. IR LEDs Length 20m
IP67,IK10, PoE
|
DH-SD29204T-GN-W
Features
1/2.7” 2Megapixel CMOS
Powerful 4x optical zoom
Support Triple-streams encoding
WDR, Day/Night(ICR), Ultra DNR
Max. 25/30fps@1080P
IVS
Support Wifi
IR distance up to 30m
|
HAC-HFW2220R-VF-IRE6
Features
1/2.8" 2.4Megapixel CMOS
25/30fps@1080P, 25/30/50/60fps@720P
High speed, long distance real-time transmission
HD and standard definition switchable
OSD Menu, control over coaxial cable
DWDR, Day/Night(ICR), AWB, AGC, BLC, 3D-DNR
2.7~12mm vari-focal lens
Max. IR LEDs length 60m, Smart IR
IP67, DC12V
|
HAC-HFW3220E-Z(H)
Features
1/2.8" 2.4Megapixel CMOS
25/30fps@1080P, 25/30/50/60fps@720P
High speed, long distance real-time transmission
HD and standard definition switchable
OSD Menu, control over coaxial cable
DWDR, Day/Night(ICR), AWB, AGC, BLC, 3D-DNR
Audio, Alarm, Heater(optional)
2.7~12mm motorized lens, Auto Iris
Max. IR LEDs length 50m, Smart IR
IP67, AC24V/DC12V
|
IPC-HFW1120RM
Features
1/3” 1.3Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
25/30fps@1.3M(1280×960)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 20m
IP67, PoE
|
